OCS-SPB Bluetooth crane scale
Dimensions and Specifications:
MODEL | Cap.(kg) | Resolution(kg) | A(mm) | C(mm) | H(mm) | N.W(kg) | G.W.(kg) |
OCS-SP-005 | 50 | 0.02 | 34 | 25 | 370 | 4 | 5 |
OCS-SP-01 | 100 | 0.05 | 34 | 25 | 370 | 4 | 5 |
OCS-SP-02 | 200 | 0.1 | 34 | 25 | 370 | 4 | 5 |
OCS-SP-03 | 300 | 0.1 | 34 | 25 | 370 | 4 | 5 |
OCS-SP-05 | 500 | 0.2 | 42 | 27 | 390 | 4.5 | 5.5 |
OCS-SP-1 | 1000 | 0.5 | 42 | 27 | 390 | 4.5 | 5.5 |
Features：
◆Enclosure:
NEMA 12/IP54 powder coated Die-Casting Aluminum, very light, easy to bring.
◆Multi-weighing units:
Kg, lb, N are selectable, kg are default unit.
◆ Multi-function operation:
Tare, Zero, Auto zero tracking, Total, Hold, Overload warning and record, operated through infrared remote controller.
◆ User-friendly design:
Large red 5 digit LED display (digit height 30mm), Battery Operated with low battery indication, Automatic turn off , power-saving function.
◆ Gravity regulation:
The acceleration of gravity can be regulated through remote controller according to different places value.
◆ Multi options:
RS-232-continuous or on demand data output, user-selectable.
Main technical data：
Accuracy Standard | According to OIML class III |
Display | 30mm (1.2″) 5digits LCD/LED |
Filtering | Low, Medium or High selectable |
Units | Kilograms or Pounds or Newtons selectable |
Resulation | 2000 to 3000 divisions standard(up to 15,000 available) |
Zero Range | 4% F.S. |
Tare Range | 100% F.S. |
Overload Indication | 100% F.S. + 9e |
Max. Safety Load | 125% F.S. |
Ultimate Load | 400% F.S. |
Battery Type | Fully sealed Lead-Acid battery, 6V/5Ah |
Battery Life | ≥60 hours |
Adapter | DC 9V/1000mA |
Operating Temperature Range | - 20℃ ~ + 50℃ |
Operating Humidity | ≤85% RH under 20℃ |
Remote Controller Distance | Max. 15m |
Battery of Remote Controller | 7# battery, 1.5Vⅹ2 |
Acceleration of Gravity | Can be regulated, the default value is 9.793 |
