OCS-SH High-temperature proof crane scale
Dimensions and Specifications:
MODEL | Cap.(kg) | Resolution(kg) | A(mm) | C(mm) | H(mm) | N.W(kg) | G.W.(kg) |
OCS-SH-1 | 1000 | 0.5 | 100 | 40 | 600 | 24 | 27 |
OCS-SH-2 | 2000 | 1 | 100 | 40 | 600 | 24 | 27 |
OCS-SH-3 | 3000 | 1 | 130 | 45 | 720 | 33 | 36 |
OCS-SH-5 | 5000 | 2 | 145 | 60 | 850 | 50 | 55 |
OCS-SH-10 | 10000 | 5 | 170 | 85 | 900 | 75 | 78 |
OCS-SH-15 | 15000 | 5 | 190 | 85 | 920 | 80 | 86 |
Features：
◆Enclosure:
NEMA 12/IP54 powder coated Foundry Cast Aluminum
◆Multi-weighing units:
Kg, lb are selectable, kg are default unit.
◆ Multi-function operation:
Tare, Zero, Auto zero tracking, Total, Hold, Overload warning and record, operated through infrared remote controller.
◆ User-friendly design:
Large red 5 digit LED display (digit height 30mm), Battery Operated with low battery indication, Automatic turn off , power-saving function.
◆ Gravity regulation:
The acceleration of gravity can be regulated through remote controller according to different places value.
◆ Multi options:
RS-232-continuous or on demand data output, user-selectable.
Wireless big screen 3″, 5″, wireless indicator 180, 280, 380, 580 can match with the scale, user-selectable.
Main technical data：
Accuracy Standard | According to OIML class III |
Display | 30mm (1.2″) 5digits LCD/LED |
Filtering | Low, Medium or High selectable |
Units | Kilograms or Pounds selectable |
Resulation | 2000 to 3000 divisions standard(up to 15,000 available) |
Zero Range | 4% F.S. |
Tare Range | 100% F.S. |
Overload Indication | 100% F.S. + 9e |
Max. Safety Load | 125% F.S. |
Ultimate Load | 400% F.S. |
Battery Type | Fully sealed Lead-Acid battery, 6V/7Ah |
Battery Life | ≥70 hours |
Adapter | DC 9V/1000mA |
Operating Humidity | ≤85% RH under 20℃ |
Remote Controller Distance | Max. 15m |
Battery of Remote Controller | 7# battery, 1.5Vⅹ2 |
Acceleration of Gravity | Can be regulated, the default value is 9.793 |
Min distance between scale and high temperature:
1000℃ | 1200℃ | 1400℃ | 1600℃ |
1.6m | 1.8m | 2m | 2.2m |
